Seasonic Gold Power Supply 750W ATX 30 (SSR-750FX3) – Premium Quality and Efficiency for PC Builds

Availability:

30 in stock
Power Output
750W
Form Factor
Intel ATX 12V
Efficiency Rating
80 PLUS Gold
Fan Size
135 mm
Fan Bearing Type
Fluid Dynamic Bearing
Fan Control
Digital Hybrid Fan Control
Fanless Operation
S3FC – Fanless until 30% load
Dimensions
140 mm (L) x 150 mm (W) x 86 mm (H)
Modularity
Fully Modular
Cable Type
Individual Black Cables with Braided Pattern
Operating Temperature
0 – 50C
MTBF
100,000 hours @ 25C, excluding fan
AC Input Voltage
100 V – 240 V
AC Input Current
10 – 5 A
AC Input Frequency
50 Hz – 60 Hz
DC Output +3.3V
20 A
DC Output +5V
20 A
DC Output +12V
62 A
DC Output -12V
0.3 A
DC Output +5VSB
3 A
Warranty
10 Years

$306.00 $383.95

30 in stock

FEATURE SUMMARY

  • ATX 3.0 and PCIe 5.0 Cable (12VHPWR)
  • 80 PLUS Gold certified
  • Compact Size – 140 mm deep
  • Top-Quality 135 mm FDB Fan
  • Digital Hybrid Fan Control
  • S3FC – Fanless until 30% load
  • Cable-free Connection Design
  • Tight Voltage Regulation
  • Gold plated connectors
  • 10 years warranty
    • Technical Specifications
    80PLUS Gold
    Cybenetics Efficiency Level TBA
    Cybenetics Noise Level TBA
    Form Factor Intel ATX 12V
    Dimensions 140 mm (L) x 150 mm (W) x 86 mm (H)
    Fan Information Fan Size 135 mm
    Fan Control S3FC – Fanless until 30% load
    Fan Bearing Fluid Dynamic Bearing
    Life Expectancy 50,000 hours at 40C, 15% – 65% RH
    Cable Information Modularity Fully Modular
    Cable type Individual Black Cables with Braided Pattern
    Electrical Features Operating Temperature 0 – 50C
    MTBF @ 25 C, excl. fan 100,000 hours
    AC Input Full Range
    Protection OPP, OVP, UVP, OCP, OTP, SCP
    Safety and Environmental Safety and EMC cTUVus, TUV, CB, CCC, BSMI, EAC, CE
    Environmental Compliance Energy Star, RoHS, WEEE, ErP Lot 6, REACH
    Warranty 10 Years

    Power Output
    AC Input
    Voltage: 100 V – 240 V
    Current: 10 – 5 A
    Frequency: 50 Hz – 60 Hz
    DC Output
    Rail
    +3.3 V
    +5 V
    +12 V
    -12 V
    +5 VSB
    Maximum Power
    20 A
    20 A
    62 A
    0.3 A
    3 A
    100 W
    744 W
    3.6 W
    15 W
    Total Continuous Power
    750 W
